Coated Graphite
A two-layer CVD stack: TiC bond coat (5–10 µm) plus SiC top coat (50–100 µm) combines thermal-match to graphite with chemical durability against silicon-rich vapours.
Features
Gradient thermal expansion – TiC layer relieves stress, prevents spallation
Non-reactive to Si melt – service life 5× longer than bare graphite in silicon environment
Dense barrier – blocks Na and Fe diffusion, keeping silicon purity >99.9999 %
Machinable after coating – final profiling possible without delamination
Industrial Applications
Energy/Solar
Directional-solidification crucibles for multi-crystal silicon ingots
LED
Susceptors for hydride-vapour-phase epitaxy (HVPE) of GaN
Semiconductor
Heaters for silicon-germanium epitaxy systems
Require more customized products and technical advice?
